NOVATRIC EXPORT
High Tension Motor Control HTMC Panel | 11kV/33kV VCB Drawout IP54 Copper Busbar 2500A | PLC Automation for Industrial Motors/Substation | DEWA Approved UAE Solutions
AED 10,000.00 - 800,000.00
/Piece
MOQ: 1 Piece
Lead Time
Quantity (Pieces)
1 - 1
>1
Lead Time (Days)
70
Negotiated
Get the latest update on price, transportation and customization.
AED 800,000.00
SKU
NOVATRIC0011
Basic Info
| Rated/Operating Voltage | 11kV / 22kV / 33kV |
| System Frequency | 50 / 60 Hz |
| Rated Current | Up to 2500A |
| Short | Circuit Capacity - 21kA for 3 seconds or 26.3kA |
| Protection Class | IP54 or IP55 (Weather-proof for outdoor) |
| Phase Configuration | 3-Phase, 3-Wire |
| Breaking Capacity | 52.5kA |
| Insulation Level | 12/28/75 kVp (Impulse withstand up to 75kVp) |
| Body Material | Fabricated up to 2.5mm thick CRCA or mild steel |
| Surface Treatment | 7-tank chemical process + powder coating (Siemens Gray RAL 7035 or White) |
| Busbars | High-conductivity EC Grade Aluminum or Copper (tinned, resin-cast insulation) |
| Mounting | Floor-mounted with bottom cable entry |
| Switchgear | Load Break Switch (LBS) or Vacuum Circuit Breaker (VCB) with earth switches |
| Load Metering | Resin-cast CTs and PTs (Accuracy Class 0.5) |
| Protection | HRC fuses and numerical relays (over-current, earth fault) |
| Accessories | Space heaters with thermostats, Electronic Trivector Meters |
| Standard Tests | IEC 62271-200, IEC 61439, CPRI Type Tested (Short Circuit, Temperature Rise, IP), Internal Arc Tested |
| Brand | Novatric |
| Common Applications | Industries & Manufacturing, Infrastructure & Utility, Commercial Buildings, Renewable Energy, Telecom |
| Country of Manufacture | India |
Packaging & Delivery
| Product Weight | 1,500.00 Kg |
| Shipping Port | Mundra Port |
