Brass Neutral Terminal – High Conductivity Electrical Connector Block for Distribution Boards, Panels & Switchgear | Corrosion Resistant, Durable Brass Terminal Strip for Industrial & Commercial Us
AED 0.10 - 0.50
/Piece
MOQ: 1000 Pieces
Lead Time
Quantity (Pieces)
1-1000
> 1001
Lead Time (Days)
3
Negotiated
Get the latest update on price, transportation and customization.
AED 0.10
SKU
BD0001
Basic Info
| Product Type | Brass Neutral Terminal |
| Material Composition | High-conductivity brass bar with zinc-plated steel screws |
| Conductor Compatibility | Copper and aluminum conductors, 5–10 AWG (approx. 4–10 mm²) |
| Voltage Rating | 250–450 V AC |
| Rated Current Capacity | 16–100 A typical range (select per variant) |
| Insulation Type | ABS or PA66 insulated base, flame-retardant to UL 94 V-2 or better |
| Mechanical Load Rating | Suitable for panel / DIN-rail mounting in distribution boards (non-structural load) |
| IP Protection Rating | Typically IP20 when installed inside an enclosed distribution board |
| Temperature Range | -20 °C to +70 °C typical (up to -30 °C to +110 °C with PA66) |
| Corrosion Resistance | Brass body with plated screws, suitable for indoor industrial and commercial environments |
| Standards Compliance | Designed to support IEC 60947 / IEC 61439 panelboard practices (select per manufacturer) |
| Bolt Specifications | Typically M4 or M5 terminal screws, e.g., M5 × 9 mm, hole diameter around 6.5 mm |
| Installation Method | Screw-fixed to panel or on insulated base / DIN rail, wire clamping by screw terminals |
| UV Resistance | Suitable for indoor use; UV-stable plastic grades available on request |
| Fire Retardancy | Insulating base in flame-retardant thermoplastic (e.g., UL 94 V-2 to V-0 class) |
| Tolerances | Machined brass bar, dimensional tolerances typically ±0.1–0.2 mm |
| Variants | 3–15 way (and higher) bars, multiple current ratings, different hole counts |
| Electrical Connectivity | Multiple screw terminals for neutral wire distribution, single or multiple feed-in points |
| Environmental Compliance | RoHS-compliant materials, free from ozone-depleting substances |
| Country of Manufacture | India |
Packaging & Delivery
| Product Weight | 0.10 Kg |
About Us
Incorporated on 14th August 2025, Brixton Power Pvt Ltd is a modern, forward-looking company rooted in the brass and metal industry. Though newly established, our directors bring over six decades of combined expertise through multiple successful ventures. We are committed to precision, innovation, and trust, leveraging generational knowledge in casting, foundry, manufacturing, trading, and global supply chains. Brixton Power Pvt Ltd manufactures and exports high-quality brass and metal components for diverse industries worldwide.
