Fire-Resistant Fixed Glass Partition Wall | 60/120-Min Fire Rated Safety Divider for Offices, Hospitals & Commercial Spaces | Tempered Glass, Frameless Design, Custom Sizes Available
Basic Info
| Door Type | Fire resistant fixed partition with glass |
| Fire Rating Duration | 30 to 180 minutes (Approved & Tested as per BS476-Pt.20-22, IS3614) |
| Air Tightness | Level 4 as per EN 12207 (Prevents inward and outward leakage of air) |
| Wind Load Resistance | Level C4 as per EN 12210 (Withstands strong pressure from wind) |
| Water Tightness | Level 8-a as per EN 12208 (Prevents water or other fluids from getting in) |
| Load Bearing Capacity | Tested as per EN 14351 (Withstands the loads of safety devices) |
| Durability Tests | 200,000 cycles as per EN 12400 (Door sustains repeated opening & closing cycles) |
| Sound Reduction | up to 42 dB as per EN 13049 (Provides sound insulation) |
| Bullet Resistance | Tested as per EN 1522 (Prevents the penetration of bullets) |
| Country of Manufacture | India |
| Reaction to fire | A2-s1, d0 (EN13501-1) |
| Impact Resistance | 1(B)1 (EN 12600) |
| UV Stability | Yes (EN ISO 12543-4), no formation of bubbles or yellowing after 2000 hours of exposure to radiation |
| Application Conditions | Avoid prolonged exposure to elevated temperatures. See Quality Guideline, Application Instructions |
| Certificate of Constancy of Performance | 0336-CPR-5064C-IL |
| Hazardous Material Contained | None |
| Dimensional tolerances (height/width) | <1000mm: -1/ +2mm |
| <2000mm: | 1/ +2.5mm |
| >2000mm: | 1/ +3mm |
| Nominal Thickness | 14 mm, 16 mm, 20 mm |
| Maximum Glass Size | Based on Certification; Please get in touch with Vetrotech representative for more information |
| Thickness Tolerance | +2/ -1 mm, +2/ -1 mm, +2/ -1 mm |
| Basic Glass | Planilux India, Planilux India, Planilux India |
| Weight | 31 kg/m2, 36 kg/m2, 46 kg/m2 |
| Sound reduction Rw (EN 140 | 3)-38 (-1,-2) dB, 39 (-2,-2) dB, 39 (-1,-2) dB |
| Light transmission (EN 410) | 86%, 86%, 84% |
| Light Reflection pL ext./int.(EN 410) | 9% / 9%, 9% / 9%, 8% / 8% |
| U Value (EN 673) | 5.0 W/m2K, 5.0 W/m2K, 4.9 W/m2K |
| g value (EN 410) | 0.72, 0.72, 0.68 |
| Energy transmission tE (EN410) | 66%, 66%, 61% |
Packaging & Delivery
| Product Weight | 80.00 Kg |
| Shipping Port | Jawaharlal Nehru Port |
About Us
Protection...Beauty...Welcome
Architects always demand performance, durability, and decorative values in construction elements. Doors must offer maximum protection... and also add beauty to the design. BASIC ARCH, with its innovative genius, offers a vast variety of doors and windows for special needs. Long service life demands performance and BASIC delivers it... Warm welcome to visitors... aesthetic excellence in design... and complete protection from housebreaking evildoers... this is our BASIC ARCH Promise. BASIC DOORS come to you in a wide variety... combinations of Puff, Honeycomb, Glasswool, Ceramic Fiber Insulation for General Doors, Clean Room Doors, Fire Doors, Acoustic Doors, Colour Coated Doors, HMPS Doors in MS, Galvanized, Zincalume, Stainless Steel, and Aluminium Sheets, with Powder Coating, PU Paint, Epoxy Primer... and there are still more options to explore. Basic is the only company in India who is having full fledged production and R&D facilities for all types of Steel Doors & Windows range at one place.
